手把手教你做PDMS管道设计

(2015-04-03 07:51:58)

标签：

节能减排

钢套钢保温管

预制直埋保温管

天津派璞

http://s11/mw690/001Xj02jty6Rck4ui1kea&690
http://s2/mw690/001Xj02jty6Rck4wbZv51&690
http://s10/mw690/001Xj02jty6Rck4ypZf69&690

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFndfjbqezxhZlx2c8gSQvw3ssqFcZkWelPayI3iaowxjdUup8hamz5Zbw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnquB7k0ThbfhcpRG0ob6zwj1WAWsbPGkNVQtUqL4cxX3e8BUXibyQKRQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnHTuqRBECjLR6jlkEvK03tv8gbyBF4af6GrzNfyfgYV2xquDlGJtL7g/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnZaPia9JZibbuSOogDMn9WKgNV62nmt9E5H8iaibiaGqmcPzJtd5rNUddZww/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn5FM9WkW4ibfbA2kVUEsQ3iaSc1g1c2Ly5DHQZaEzXJEZP7iaRTJeGWmfQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn3cE5oMyLEQNoCH5Iugak29diaUEYEYlvhOEFzb1hZrHBJxrm34QSJcQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnPY6ZiaoUgRGibb6tQO4PVibBrOJXzEESrKugx4mQHnjcdhQ4H5OvRVSvw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnTdqmXJRmEhe3j72NGgtrhptVuBntRfaOGl10Y618wak1BLxph6E4FQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnKUxdoic1gfGssExDJOkqsBsChB8cOAlbPY2EHnGibI8YPFb6o4mMKwQg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnctQFAazv5Bp1HU8sfGh7iaJl2YlD5b1MhbKezaLkQnK2G0hjwlFkGpg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnak32thQTYNowOmaqxopejgUdkarQktKntX8VTeKRvsFjE2iazdJgcsg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnP3LjZjYYew1fBmYIv8lYpLdya1iasgmRSRdJvo3xb1MDMIiagF5icm3iaw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn9nTYepR1bHflNvccjuUd4bO5ZtKnj9nRmUXlAJ1VJQFEOIMapZibicOA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFniba9Unl9ENYZCBus5Wlsb0IshlkhOG2eX4MXC6omibcicVXPEicnx0iaSicQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnDwsKL33Yb3ibdAZkHFoCa60p9AhfaFQzxJ5DY8LsMtHDicMgSh19kbUA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnwkzzFHiacBVOc6k8luAtg7BIviaABsf50hbIdcj7ibpFIL43iaUe30FbvA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn4K42DL6Yse2YSrxjFycYRiaciaWohx1ZgOm4Hwic8Gr6c1Vc2bytGKJDQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnNgDgjr7icGofGk7kE4XbPr9DYicdPomSTGbW9AURCU8bo6fgdAeXqr1Q/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn8FNaD12fzNtEKKCVqMtXREOrhZuLbUDsQibia5Wso8Dts5k4Udw1RBpg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnxicxdfOGibkD0Whc5fulPEBZVUJneDg8dictzQiarbAibNlK0YUpkzicRpUA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnxoRWKq3RZVKUNqT3WrBTTTGEITlSVWnePNBZfh7EjftciblVOPUK30g/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnMhDafIqHqsDSOjm6FEpc3L63iaIXBubiamic4nJ9m3jNTbyQTTlvmbDsQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnYM9az9mCLicpCxSq56kSyRvG4zWHib6mFyiaEkZYIf4jD1e9rN2N7BmqA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnebqz2Xx7VgrRLYDRv4JK9dRqCibGOmG8QqMDq0ZzGmibyqBkhJEHAmtg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnYv4u2KUsBUUiavt0h8GTOKFRUHa7QxlPYoYzX92xlEP8egibJNLBtBrQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn8z3pQzwKvhMA8YEZIoicgyez81xC7gt3XGDKxOfCgzRwAd48DNsmsPQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnbHEcAuQGkic190M8cts0CuwIv7Bt9zqs5TVkgzc8FqwyGoG5iaWN28tQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnB52mGeeSS4wf6720nPCzCPzv93YlQUiahlJWWYp4j4q4C5EG4VMpU7A/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnWywnosh5LOCkVf6md5UJHCqaMg6TXicjGh8F3Hx9H3B14DarTwIZPnQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnfnKiaxmg6LEqKavjPJrgNywZfmfrOMIEiaSbKHFSIHUbFZ0ic9cvbWZXA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn2dPb3OTicU6gU6tpUdv9mgaNH50HgY36dDSyU3UecOJribKtWqTmjI1w/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnTtLhkXcpQtwwib7ywDjuDYyiaRK2eELzjMXtyrCXXIuqxmE8twGgD9aw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnxQhQGhcnPobibyibcGVYHoJibFWlebNdEcR17ibb5WK7h8Mtib9upPoXfTg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnUZSA88jjHEaFBYqyeR7PBrqfbTwvw57LBNQqBgne8sU0WJvYeqg9pQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFncNSOGWXOwjTqFicjZOFvGicckOeo17UH5icLgj5PLRzVlbUOSPI1fAbxw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnyutTzyThggAN35eBcZslFChMjA3DUJHg9k7icgia4tqTMJHWSooKdTuw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnLyuqnudENVz3YZtjWyXnia17sRyzttAKTB52BEd6fMTlEY5PGLyJRHg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn4VmqnfooK4wbkUsfI8Qic4pzfnAx88osqCuySTgq2uMpjAVovlUxeqA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnGq0K0rVAUrGpzFM92ykOHJ97ia6XsZhRLnOM1aCdfu1sWKqRwoPbtoA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFniaRWOiadvhlribQyPSk0Iiczv3NLibvTEuPiaiarkAXicviceSlDDyBnJCbXPyw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnfxibf08w59S2rjwF0hiccn9uCItjVgMjzricM5AtluqlfcOp4LBs1RVpQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn2goqT3gnL7y5TefykhyMm5y4yicoXLKCKHP7Lxibogy0qQMib0ib575e5Q/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnSa7V6Uf8okYbSNqbc8uactVgoT8CQnOAwpvZ5PHxrkVHt2ibwnCYT3w/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn3MsbIv3LhNvS93XBZTnqkc3GE0rFEyaxOLW6O5VEH2CU43H9kQhdzQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnBrS80iakxoVMC00Dvsk3mk9zsAHPeP9VCgc0Np0hn41lvObI2oAkL0A/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnCy2lOFTeZgribzQiaFYNbxicYOIiaEfLDID868KwKFaVnX8Cy26icbxebAQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnouQEjL2m0ianAUH3WFfFupZGhKhDYQUpVhZK84Jub9xWa8SnYyHkohA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn9OJZtQoa4F0icRAl8bwg5bNSAzuwoskyevxAqlfW8JibPxjueibOfkzBA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnGibydrbs4Z88iajzsb0Piaa8Mm1SZ5eicePftQweRYgicFsETaOiam4yOUmA/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnJJTLq17hiabAzK9NNmLMweagtNqavNLpXhaWf92Vy8Lov8Tdhrqia84A/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFn96cOuWn0prjnlPicsDzqF0LqvYVTlLuHOlnqiabMvZyN1jsL3vY0Qfwg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnXjoibsskBliblMqibnejh5ruN5Wwic2eoKH8IfvPxkB41HqIWlpibrLic8zw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnNzsVZnejKdJwwMD5cx9mI1FzsM0iak8PExvTf5uFDM0L5ItuzUDLsPg/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnlJIdo7qBMPQPmzdic7fZhOyaH1fiaNbgdpoNicw7pvN5LVZyV8R6NKr3w/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnibCs81ias3Q8vvvFNoMms1SJvMgvvWlxnhKRqsibDmBchlibXtiaC6LuKMQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFntVhlCO4UzCic5dw8dr2cwZKnOwAnJklN1nEohEyU1bOOab7Y9Ok953Q/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnLo1TicjnfoKdj71a4L99yPmliag2oqJUsGuad4ggBEa0mmxlU5WLPUUw/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnRFY1gz1TEhltibPxy5ujElX8yG5Rh37WlR1E6574oApGjzREFhST2YQ/640?tp=webp&wxfrom=5

http://mmbiz.qpic.cn/mmbiz/vSABwyURAVgib4KrpzcVZ9TmwWrG1zDFnxQib3yEZYiaH2OGJrTdTMoMbGuEYY70HnWUic5Bvx3FnjNq1RG7c5eOGQ/640?tp=webp&wxfrom=5
